DMC2450UV-7

Part No DMC2450UV-7
Manufacturer Diodes Incorporated
Catalog Transistors - FETs, MOSFETs - RF
Description COMPLEMENTARY PAIR ENHANCEMENT MODE MOSFET
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
FET Type N and P-Channel
FET Feature Standard
Drain Source Voltage 20V
Current - Continuous Drain (Id) @ 25°C 1.03A, 700mA
Rds On (Maximum) @ Id, Vgs 480 mOhm @ 200mA, 5V
Vgs(th) (Maximum) @ Id 900mV @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 0.5nC @ 4.5V
Input Capacitance (Ciss) (Maximum) @ Vds 37.1pF @ 10V
Power - Max 450mW
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Package SOT-563, SOT-666
Manufacturer Package SOT-563
Win Source Part Number 1168039-DMC2450UV-7
Manufacturer Homepage www.diodes.com
Family Name DMC2450UV
Introduction Date September 30, 2015
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2031
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DMC2450UV-7 CAD Model

Description

The DMC2450UV-7 is a state-of-the-art MOSFET brought to you by Diodes Incorporated, a leading manufacturer in the semiconductor market. This compact, surface-mount device is designed to deliver high efficiency and reliability for a wide range of applications.

Key Features

  • Low On-Resistance: The MOSFET features ultra-low on-resistance, which significantly reduces conduction losses and enhances overall efficiency.
  • High-Speed Switching: Optimized for fast switching applications, the DMC2450UV-7 ensures minimal delays in electronic circuits.
  • Low Gate Charge: A low gate charge allows for reduced switching energy, making it suitable for high-frequency operations.
  • RoHS Compliant: Adhering to environmental standards, this product is RoHS compliant, minimizing the impact on the environment.

Applications

The DMC2450UV-7 is versatile and can be used in a variety of applications, including:

  • Power Management
  • DC/DC Converters
  • Battery Management Systems
  • Load Switches
  • Motor Drives

Technical Specifications

With a continuous drain current of 4.2 A and a maximum drain-source voltage of 20 V, the DMC2450UV-7 is capable of handling a range of power requirements. Its SOT-23 package is not only space-saving but also ensures a low thermal resistance path for heat dissipation.

Quality and Reliability

Diodes Incorporated is committed to providing products that meet the highest standards of quality and reliability. The DMC2450UV-7 is no exception, undergoing rigorous testing to ensure it performs under various conditions and throughout its intended lifespan.

Ordering Information

To purchase the DMC2450UV-7 or to obtain more information about pricing and availability, please visit Diodes Incorporated's official website or contact an authorized distributor. This product is available in tape and reel packaging, facilitating easy integration into automated manufacturing processes.
