DMN6040SVT-7 - N-Channel Enhancement Mode Field Effect Transistor

The DMN6040SVT-7 is a high-performance, N-Channel enhancement mode field effect transistor (FET) designed and manufactured by Diodes Incorporated. This FET is part of their extensive range of MOSFETs that are engineered to deliver efficient power management and conversion in various electronic applications. The DMN6040SVT-7 is particularly well-suited for portable and battery-powered devices, thanks to its low on-resistance and minimal gate charge.

Key Features:

• Low On-Resistance: The device offers an exceptionally low on-resistance (R<sub>DS(on)) of just 13.5 mOhms at V<sub>GS = 10V, which translates to reduced conduction losses and improved overall efficiency.
• High Continuous Drain Current: It supports a high continuous drain current (I<sub>D) of up to 6.5A, making it capable of handling substantial current loads without performance degradation.
• Low Threshold Voltage: With a low threshold voltage (V<sub>GS(th)), this MOSFET ensures a quick and reliable start-up and operation at lower gate voltages, which is advantageous for low-voltage applications.
• Power Dissipation: It is rated for a power dissipation (P<sub>D) of 2.5W, ensuring that the device can manage power effectively without overheating.
• Surface Mount Package: The DMN6040SVT-7 comes in a compact, surface-mount SOT-23 package, making it ideal for space-constrained applications.

Applications:

The versatility of the DMN6040SVT-7 allows it to be used in a wide array of applications, including but not limited to:

• Power management circuits
• DC-DC converters
• Battery-powered devices
• Load switches
• Motor control systems

Quality and Reliability:

Diodes Incorporated is committed to providing high-quality products. The DMN6040SVT-7 is built to meet stringent quality standards, ensuring reliability and performance consistency. It is RoHS compliant, reflecting the company's dedication to environmental responsibility.
