MJD32CUQ-13

Part No MJD32CUQ-13
Manufacturer Diodes Incorporated
Catalog Transistors (BJT) - Single
Description TRANS PNP 100V 3A TO252
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single Bipolar Transistors
Mfr Diodes Incorporated
Series Automotive, AEC-Q101
Package Tape & Reel
Product Status Active
Transistor Type PNP
Current - Collector (Ic) (Max) 3 A
Voltage - Collector Emitter Breakdown (Max) 100 V
Vce Saturation (Max) @ Ib, Ic 700mV @ 375mA, 3A
Current - Collector Cutoff (Max) 1µA
DC Current Gain (hFE) (Min) @ Ic, Vce 25 @ 1A, 4V
Power - Max 1.6 W
Frequency - Transition 3MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package TO-252, (D-Pak)
Base Product Number MJD32
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 1377128-MJD32CUQ-13
Ultra Librarian 3D Model Ultra Librarian MJD32CUQ-13 CAD Model

Description

Product Overview: MJD32CUQ-13 by Diodes Incorporated

The MJD32CUQ-13 is a high-quality bipolar junction transistor (BJT) developed by Diodes Incorporated, a leading manufacturer in the semiconductor market. This PNP transistor is designed for general-purpose amplifier and switching applications, offering a combination of low on-state voltage and high current capability.

Key Features

  • Transistor Type: The MJD32CUQ-13 is a PNP transistor, which means it is controlled by the flow of minority carriers (holes in this case) across its junctions.
  • High Current Handling: With a continuous collector current rating of up to 3A, this transistor can handle significant current, making it suitable for a variety of power applications.
  • Voltage Ratings: It has a collector-emitter voltage (VCEO) of -100V, ensuring it can manage substantial voltage levels in circuit designs.
  • Power Dissipation: The device is capable of dissipating up to 20W of power, which is substantial for its size and allows it to be used in power-intensive scenarios.
  • Package: The MJD32CUQ-13 comes in a DPAK (TO-252) package, which is known for its compact footprint and excellent thermal performance.
  • Complementary NPN Type: It has a complementary NPN counterpart, making it ideal for use in push-pull amplifier configurations or other complementary applications.

Applications

The MJD32CUQ-13 is versatile and can be used in a broad range of applications, including:

  • Power management circuits
  • Linear amplifiers
  • Switching regulators
  • Motor control circuits
  • Audio amplifiers

Quality and Reliability

Diodes Incorporated ensures that the MJD32CUQ-13 meets the highest standards of quality and reliability. This product is tested rigorously to guarantee performance in diverse conditions and is compliant with RoHS standards, making it an environmentally friendly choice for modern electronic applications.
