The PAM8006ATR from Diodes Incorporated is a high-performance, filter-less Class-D audio amplifier that is highly efficient and capable of driving stereo speakers with up to 10W per channel. Its compact size and high efficiency make it an ideal choice for portable and space-constrained applications while providing exceptional sound quality.

Key Features

• Output Power: Delivers 10W into 8Ω speakers with a 13V supply.
• High-Efficiency: Class-D operation means low heat dissipation and energy consumption.
• Filter-Less Design: Reduces external component count and system cost.
• Low EMI: Spread spectrum control reduces electromagnetic interference, simplifying compliance with regulatory standards.
• Robust Protection: Features over-temperature, under-voltage, over-voltage, and short-circuit protection.
• Advanced Modulation Schemes: Supports both BD modulation and fixed frequency modulation for improved performance.

Applications

The PAM8006ATR is versatile and can be used in a variety of audio applications. It is particularly well-suited for:

• LCD TVs and Monitors
• Portable Speakers
• Wireless Speakers
• Soundbars
• Home Theater Systems

Technical Specifications

Parameter Value Supply Voltage 8V to 26V Output Power (per channel) 10W into 8Ω Efficiency Up to 90% THD+N Operating Temperature -40°C to +85°C

The PAM8006ATR is offered in a TSSOP-28 package, providing a space-saving solution for modern audio applications. Its ability to operate without the need for an external heat sink further enhances its appeal for compact electronic devices.
