DRQ127-R47-R Eaton Bussmann – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

DRQ127-R47-R

Part No DRQ127-R47-R
Manufacturer Eaton Bussmann
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 419NH SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Coils 2
Inductance - Connected In Parallel 419 nH
Inductance - Connected In Series 1.676 µH
Tolerance ±20%
Current Rating - Parallel 17.9 A
Current Rating - Series 8.94 A
Current Saturation - Parallel 56 A
Current Saturation - Series 28 A
DC Resistance (DCR) - Parallel 1.95mOhm
DC Resistance (DCR) - Series 7.8mOhm
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height 0.315\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1532045-DRQ127-R47-R
Ultra Librarian 3D Model Ultra Librarian DRQ127-R47-R CAD Model
