HCM1103-4R7-R

Name: HCM1103-4R7-R
Brand: Eaton Bussmann
SKU: 967045
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	HCM1103-4R7-R
Manufacturer	Eaton Bussmann
Catalog	Fixed Inductors
Description	FIXED IND 4.7UH 7A 22.5 MOHM SMD / 4.7 µH Shielded Drum Core, Wirewound Inductor 7 A 22.5mOhm Max Nonstandard
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Eaton - Electronics Division
Series	HCM1103
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Iron Powder
Inductance	4.7 µH
Tolerance	±20%
Current Rating (Amps)	7 A
Current - Saturation (Isat)	13A
Shielding	Shielded
DC Resistance (DCR)	22.5mOhm Max
Temperature Range - Operating	-55°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.437" L x 0.394" W (11.10mm x 10.00mm)
Height - Seated (Max)	0.118" (3.00mm)
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.50.8000
Other Names	283-4131-1,HCM11034R7R,283-4131-2,283-4131-6
Standard Package	1,000
Win Source Part Number	967045-HCM1103-4R7-R
Ultra Librarian 3D Model	Ultra Librarian HCM1103-4R7-R CAD Model

Alternative Products

Description

The Eaton - Electronics Division HCM1103 is a drum core, wirewound inductor with a shielding of 4.7 µH.

Product Name: HCM1103
Manufacturer: Eaton - Electronics Division
Type: Drum Core, Wirewound Inductor
Shielding: Yes
Inductance: 4.7 µH
Height: 0.118" (3.00mm)
DCR: 22.5mOhm Max
Mounting: SMD (SMT)
Tolerance: ±20%
Material-Core: Iron Powder
Temperature Range: -55°C ~ 125°C
Dimension: 0.437" L x 0.394" W (11.10mm x 10.00mm)
MSL: 1 (Unlimited)
Current Rating: 7 A
Inductance Frequency-Test: 100 kHz
HTSUS: 8504.50.8000
