WCL3225-391-R

Name: WCL3225-391-R
Brand: Eaton Bussmann
SKU: 1104549
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	WCL3225-391-R
Manufacturer	Eaton Bussmann
Catalog	Fixed Inductors
Description	FIXED IND 390UH 45MA 21.5OHM SMD / 390 µH Unshielded Drum Core, Wirewound Inductor 45 mA 21.5Ohm Max 1210 (3225 Metric)
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Eaton - Electronics Division
Series	WCL3225
Package	Tape & Reel (TR)
Type	Drum Core, Wirewound
Material - Core	Ceramic
Inductance	390 µH
Tolerance	±5%
Current Rating (Amps)	45 mA
Shielding	Unshielded
DC Resistance (DCR)	21.5Ohm Max
Q @ Freq	8 @ 796kHz
Frequency - Self Resonant	2.2MHz
Temperature Range - Operating	-40°C ~ 85°C
Inductance Frequency - Test	796 kHz
Mounting	SMD (SMT)
Package / Case	1210 (3225 Metric)
Supplier Device Package	1210
Dimension	0.138" L x 0.114" W (3.50mm x 2.90mm)
Height - Seated (Max)	0.089" (2.25mm)
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.50.8000
Other Names	283-WCL3225-391-RTR
Standard Package	2,000
Win Source Part Number	1104549-WCL3225-391-R
Ultra Librarian 3D Model	Ultra Librarian WCL3225-391-R CAD Model

Alternative Products

Description

The Eaton WCL3225-391-R is a fixed inductor with an inductance of 390 µH.

Manufacturer: Eaton
Inductance: 390 µH
Type: Drum core, wirewound
Core Material: Ceramic
Q Value: 8 @ 796kHz
Frequency Self-Resonant: 2.2MHz
DC Resistance: 21.5 ohms max
Current Rating: 45 mA
Package: 1210 (3225 Metric)
Mounting Type: SMD (SMT)
Tolerance: ±5%
Shielding: Unshielded
RoHS Compliant: Yes
Operating Temperature: -40°C ~ 85°C
Alternative Part: 283-WCL3225-391-RTR
