Products specifications Report Issue?

RoHS State Request Verification
Manufacturer ELM Electronics
Win Source Part Number 1171755-ELM9727CBA
Manufacturer Homepage www.elmelectronics.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ELM9727CBA CAD Model

Description

The ELM9727CBA is an integrated circuit from ELM Electronics, commonly used as an OBD II scan tool interpreter. This chip allows microcontrollers and other devices to interface with the On-Board Diagnostics II (OBD II) systems found in modern vehicles. It decodes and interprets the data transmitted by the vehicle's ECU (Engine Control Unit) according to the SAE J1979 standard.

Applications:

  • OBD II scan tools
  • Automotive diagnostics equipment
  • Vehicle telematics systems
  • DIY automotive projects
  • Embedded systems for vehicle data logging

Features:

  • Supports multiple OBD II protocols (e.g., ISO 15765-4 CAN, ISO 9141-2, SAE J1850 PWM/VPW)
  • Automatic protocol detection
  • Serial interface for communication with microcontrollers
  • Low power consumption
  • Built-in EEPROM for configuration storage

Benefits:

  • Simplifies the development of OBD II scan tools and diagnostic equipment.
  • Reduces the need for complex software implementation by handling protocol interpretation.
  • Allows for easy integration with microcontrollers and other embedded systems.
  • Extends battery life in portable diagnostic tools due to its low power consumption.
  • Provides a flexible and configurable solution with its built-in EEPROM.

Additional Details:

The ELM9727CBA handles the complexities of the various OBD II communication protocols, allowing developers to focus on the application-level functionality of their diagnostic tools. It automatically detects the protocol used by the vehicle and interprets the data accordingly. The chip communicates with a microcontroller via a simple serial interface (UART). It is designed to operate from a single 5V power supply. Further details, including pinouts and electrical characteristics, can be found in the official datasheet from ELM Electronics.
