The FZ1200R12KE3 is an IGBT (Insulated Gate Bipolar Transistor) module manufactured by eupec GmbH (now Infineon Technologies). This module is designed for high-power switching applications and is commonly used in industrial drives, power supplies, and renewable energy systems.

Applications

• Industrial Drives
• Power Supplies
• Renewable Energy Systems (e.g., wind turbines, solar inverters)
• Traction applications
• UPS (Uninterruptible Power Supplies)
• Welding equipment

Features

• 1200A Collector Current
• 1200V Blocking Voltage
• Low VCE(sat) (Collector-Emitter Saturation Voltage)
• Fast Switching Speed
• Integrated Temperature Sensor (NTC)
• Isolated Baseplate
• RoHS Compliant

Benefits

• High efficiency due to low switching losses
• Reduced system size and cost
• Improved reliability
• Simplified thermal management
• Protection against over-temperature conditions
• Increased power density

Additional Details

The FZ1200R12KE3 IGBT module features a robust design and is suitable for demanding applications. The integrated temperature sensor allows for precise monitoring and control of the module's temperature, preventing overheating and ensuring safe operation. The isolated baseplate simplifies mounting and provides electrical isolation between the module and the heatsink. The module's low VCE(sat) contributes to lower power dissipation and higher efficiency. The fast switching speed minimizes switching losses, further improving efficiency. This IGBT module is designed for long-term reliability and high performance in various power electronic applications.
