BC80740MTF Real Image BC80740MTF Real Image
Same model may have multiple batches, images only for reference.
BC80740MTF Real Image BC80740MTF Real Image
BC80740MTF Real Image BC80740MTF Real Image
Same model may have multiple batches, images only for reference.

BC80740MTF

Part No BC80740MTF
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS PNP 45V 0.8A SOT23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Transistor Polarity PNP
Maximum Current Collector 800mA
VCEO Maximum Collector-Emitter Breakdown Voltage 45V
Max Vce (sat) 700mV @ 50mA, 500mA
Collector Cut-off Current(Max) 100nA
Typical Gain (hFE) (Min) 250 @ 100mA, 1V
Maximum Power Dissipation 310mW
Frequency - Transition 100MHz
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 1022398-BC80740MTF
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Audio, Power Management, Industrial
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian BC80740MTF CAD Model

Description

The Fairchild/ON Semiconductor BC80740MTF is a PNP transistor that is widely used in audio, power management, and industrial applications.

  • Manufacturer: Fairchild/ON Semiconductor
  • Current Collector (Max): 800mA
  • VCEO (Max): 45V
  • Case/Package: SOT-23-3
  • Applications: Audio, Power Management, Industrial
  • Features: High Gain (hFE), Low Collector Cut-off Current
  • Packaging: Reel/TR
  • Quantity per Package: 3k
