Same model may have multiple batches, images only for reference.

FDB33N25TM

Name: FDB33N25TM
Brand: Fairchild/ON Semiconductor
SKU: 453018
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDB33N25TM
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 250V 33A D2PAK
Datasheet	FDB33N25TM Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	250V
Continuous Drain Current at 25°C	33A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	5V @ 250μA
Max Gate Charge	48nC @ 10V
Max Input Capacitance	2135pF @ 25V
Maximum Gate-Source Voltage	±30V
Power Dissipation (Max)	235W (Tc)
Maximum Rds On at Id,Vgs	94 mOhm @ 16.5A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK (TO-263AB)
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	1037969-FDB33N25TM
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	800
Ultra Librarian 3D Model	Ultra Librarian FDB33N25TM CAD Model

Alternative Products

Description

Semiconductor FDB33N25M is an n-channel polarity product of MOSFET technology. This is an active part of the supply and demand balance, with 30% of false threats in the open market. The part number of Yingyuan is 1037969-fdb33n25tm, which comes from a D2 Pakistan (to 263AB) package. This product has a discharge source breakdown voltage of 250V and a continuous discharge current of 33A (TC) at 25 ℃. The maximum RDS on IDS has an average value of 94 MOM, 16.5a, and 10V. The manufacturer's homepage is www. Fairchatham. com.
