FDC6401N Fairchild/ON Semiconductor FDC6401N Real Image FDC6401N real image4031 FDC6401N Real Image
Same model may have multiple batches, images only for reference.
FDC6401N Fairchild/ON Semiconductor FDC6401N Real Image FDC6401N real image4031 FDC6401N Real Image
FDC6401N Fairchild/ON Semiconductor FDC6401N Real Image FDC6401N real image4031 FDC6401N Real Image
Same model may have multiple batches, images only for reference.

FDC6401N

Part No FDC6401N
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 20V 3A SSOT-6
Datasheet
FDC6401N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 3A
Maximum Rds On at Id,Vgs 70 mOhm @ 3A, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 4.6nC @ 4.5V
Max Input Capacitance 324pF @ 10V
Maximum Power Dissipation 700mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SuperSOT-6
Win Source Part Number 015919-FDC6401N
Family Name FDC6401N
Introduction Date October 01, 2001
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Power Management
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDC6401N CAD Model

Description

FDC6401N N-Channel PowerTrench MOSFET

The FDC6401N is a high-performance N-channel PowerTrench MOSFET, designed to offer excellent efficiency in power-sensitive applications. With its advanced trench technology, it provides minimized power loss and thermal resistance.

Applications

  • Load switch applications
  • Power supply circuits
  • Switching regulators

Features and Benefits

  • Enhanced thermal performance with low RDS(on)
  • Capable of handling significant pulsed currents up to 12A
  • Compact packaging for optimized board design

Additional Details

Engineered for efficiency, the FDC6401N supports a maximum drain-source voltage of 20V, making it suitable for a variety of power systems.
