FDD3672 Real Image FDD3672 Real Image1 FDD3672 Real Image2
Same model may have multiple batches, images only for reference.
FDD3672 Real Image FDD3672 Real Image1 FDD3672 Real Image2
FDD3672 Real Image FDD3672 Real Image1 FDD3672 Real Image2
Same model may have multiple batches, images only for reference.

FDD3672

Part No FDD3672
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 100V 6.5A 3-Pin(2+Tab) DPAK T/R / MOSFET N-CH 100V 44A DPAK-3
Datasheet
FDD3672 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 44A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 36nC @ 10V
Max Input Capacitance 1635pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 144W (Tc)
Maximum Rds On at Id,Vgs 47 mOhm @ 21A, 6V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252AA
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 066922-FDD3672
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Industrial
Family Name FDD3672
Introduction Date June 13, 2002
ECCN EAR99
Country of Origin China, Philippines, Republic of Korea, United States of America
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian FDD3672 CAD Model

Description

FDD3672 - Robust N-Channel MOSFET Device

The FDD3672 is engineered to deliver efficiency and reliability in electronic applications. Renowned for its ease of use and consistent performance, it's a go-to choice for demanding environments.

  • Applications:
    • Automotive electronics
    • Power management modules
    • Industrial motor controls
    • Telecommunications
  • Features and Benefits:
    • Low On-state Resistance
    • Fast Switching Speed
    • Superior Thermal Capacity
  • Additional Details:
    • Maximum Drain Current: 72A
    • Drain-Source Voltage: 100V
    • Package Type: TO-252
