FDD4685

Name: FDD4685
Brand: Fairchild/ON Semiconductor
SKU: 453119
Availability: InStock
Rating: 4.93 (74 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDD4685
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 40V 8.4A DPAK
Datasheet	FDD4685 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	40V
Continuous Drain Current at 25°C	8.4A (Ta), 32A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	27nC @ 5V
Max Input Capacitance	2380pF @ 20V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	69W (Tc)
Maximum Rds On at Id,Vgs	27 mOhm @ 8.4A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	D-PAK (TO-252AA)
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	1038070-FDD4685
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	2,500
Ultra Librarian 3D Model	Ultra Librarian FDD4685 CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor FDD4685 is a P-Channel MOSFET technology component used in various electronic devices.

Maximum Power Dissipation: 69W (Tc)
Drain-Source Breakdown Voltage: 40V
Maximum Rds On @ Id,Vgs: 27 mOhm @ 8.4A, 10V
