FDD6685

Part No FDD6685
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 11A DPAK
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 11A (Ta), 40A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 24nC @ 5V
Max Input Capacitance 1715pF @ 15V
Maximum Gate-Source Voltage ±25V
Power Dissipation (Max) 52W (Ta)
Maximum Rds On at Id,Vgs 20 mOhm @ 11A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 131865-FDD6685
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FDD6685 CAD Model

Description

Description

The FDD6685 is a high-performance N-channel MOSFET that offers excellent efficiency and power handling capabilities. Designed for robust performance in a variety of applications, this MOSFET is engineered to deliver superior switching speed and thermal characteristics.

Applications

  • Power Supply Circuits
  • DC-DC Converters
  • Motor Control
  • Load Switches

Features and Benefits

  • Low On-Resistance: Enhances efficiency and reduces power loss.
  • Fast Switching Speed: Suitable for high-speed applications.
  • High Thermal Performance: Ensures reliability under stress.

Additional Details

Its compact package design allows it to be easily integrated into space-constrained environments. The FDD6685 MOSFET is particularly useful in applications where space is at a premium and efficiency is crucial.
