FDD770N15A Real Image FDD770N15A real image15431 FDD770N15A Real Image
Same model may have multiple batches, images only for reference.
FDD770N15A Real Image FDD770N15A real image15431 FDD770N15A Real Image
FDD770N15A Real Image FDD770N15A real image15431 FDD770N15A Real Image
Same model may have multiple batches, images only for reference.

FDD770N15A

Part No FDD770N15A
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N CH 150V 18A DPAK
Datasheet
FDD770N15A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 150V
Continuous Drain Current at 25°C 18A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 11nC @ 10V
Max Input Capacitance 765pF @ 75V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 56.8W (Tc)
Maximum Rds On at Id,Vgs 77 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1038106-FDD770N15A
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FDD770N15A CAD Model

Description

The Fairchild/ON Semiconductor FDD770N15A is an N-channel MOSFET that comes in a D-Pak package.

  • Maximum Power Dissipation: 56.8W
  • Breakdown Voltage: 150V
