FDG8850NZ Real Image FDG8850NZ Real Image1 FDG8850NZ Real Image2
Same model may have multiple batches, images only for reference.
FDG8850NZ Real Image FDG8850NZ Real Image1 FDG8850NZ Real Image2
FDG8850NZ Real Image FDG8850NZ Real Image1 FDG8850NZ Real Image2
Same model may have multiple batches, images only for reference.

FDG8850NZ

Part No FDG8850NZ
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 30V 0.75A SC70-6
Datasheet
FDG8850NZ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 750mA
Maximum Rds On at Id,Vgs 400 mOhm @ 750mA, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 1.44nC @ 4.5V
Max Input Capacitance 120pF @ 10V
Maximum Power Dissipation 300mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-6
Win Source Part Number 1038153-FDG8850NZ
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial, Power Management
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDG8850NZ CAD Model

Description

The Fairchild/ON Semiconductor FET is a high-performance dual 2 N-channel FET designed for use in industrial and power management applications.

  • Gate: Logic Level
  • Package: SC-70-6
  • Maximum Power Dissipation: 300mW
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 750mA @ 25°C
  • Gate-Source Threshold Voltage: 1.5V @ 250μA
  • Maximum Gate Charge: 1.44nC @ 4.5V
  • Maximum Input Capacitance: 120pF @ 10V
  • Maximum Rds On: 400 mOhm @ 750mA, 4.5V
  • RoHS Compliant: Yes
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Package Quantity: 3k pcs
