FDMS8670AS Fairchild/ON Semiconductor FDMS8670AS Real Image FDMS8670AS label picture FDMS8670AS Real Image1 FDMS8670AS Real Image2
Same model may have multiple batches, images only for reference.
FDMS8670AS Fairchild/ON Semiconductor FDMS8670AS Real Image FDMS8670AS label picture FDMS8670AS Real Image1 FDMS8670AS Real Image2
FDMS8670AS Fairchild/ON Semiconductor FDMS8670AS Real Image FDMS8670AS label picture FDMS8670AS Real Image1 FDMS8670AS Real Image2
Same model may have multiple batches, images only for reference.

FDMS8670AS

Part No FDMS8670AS
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 23A POWER56
Datasheet
FDMS8670AS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 23A (Ta), 42A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 1mA
Max Gate Charge 55nC @ 10V
Max Input Capacitance 3615pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 78W (Tc)
Maximum Rds On at Id,Vgs 3 mOhm @ 23A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package Power56
Dimension 8-PowerTDFN
Win Source Part Number 125640-FDMS8670AS
Family Name FDMS8670AS
Introduction Date July 23, 2007
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Computers & Computer Peripherals, Industrial
Ultra Librarian 3D Model Ultra Librarian FDMS8670AS CAD Model

Description

The Fairchild/ON Semiconductor 125640-FDMS8670AS is a high-popularity electronic component that is widely used in various industries, including power management, computers, and computer peripherals.

  • Package: Reel - TR
  • Mounting Technology: SMD (SMT)
  • Polarity: N-Channel
  • Power Dissipation: 2.5W (Ta) / 78W (Tc)
  • Family Name: FDMS8670AS
  • Lifecycle Status: Obsolete (EOL)
  • Operating Temperature: -55°C to 150°C (TJ)
  • Case/Package: Power56, 8-PowerTDFN
