H11G2SR2M Real Image H11G2SR2M Real Image1 H11G2SR2M Real Image2 H11G2SR2M Real Image3
Same model may have multiple batches, images only for reference.
H11G2SR2M Real Image H11G2SR2M Real Image1 H11G2SR2M Real Image2 H11G2SR2M Real Image3
H11G2SR2M Real Image H11G2SR2M Real Image1 H11G2SR2M Real Image2 H11G2SR2M Real Image3
Same model may have multiple batches, images only for reference.

H11G2SR2M

Part No H11G2SR2M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 4.17KV DARL W/BASE 6SMD
Datasheet
H11G2SR2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 4170Vrms
Minimum DC Current Transfer Ratio 1000% @ 10mA
Switching Turn-On and Turn-Off Time 5μs, 100μs
Input Type DC
Output Type Darlington with Base
Maximum Output Voltage 80V
Forward Voltage 1.3V
Continuous forward current- Max 60mA
Vce Saturation (Max) 1V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 6-SMD
Win Source Part Number 001454-H11G2SR2M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name H11G2M
Introduction Date May 01, 2007
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2025
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian H11G2SR2M CAD Model

Description

The Fairchild/ON Semiconductor 001454-H11G2SR2M is a Darlington with Base output type isolator designed for high efficiency and reliability.

  • Minimum DC Current Transfer Ratio: 1000% @ 10mA
  • Switching Turn-On Time: 5μs
  • Switching Turn-Off Time: 100μs
  • Isolation Voltage: 4170Vrms
  • Package: 6-SMD
  • Manufacturer: Fairchild/ON Semiconductor
  • Part Number: 001454-H11G2SR2M
