The KA5H0265R is a Fairchild Power Switch (FPS) integrated circuit manufactured by Fairchild Semiconductor (now ON Semiconductor). It is designed for offline switch-mode power supplies (SMPS). This IC integrates a power MOSFET and a current mode PWM (Pulse Width Modulation) controller, providing a cost-effective and efficient solution for various power supply applications. It is commonly used in adapters, chargers, and auxiliary power supplies.

Applications:

• Adapters: Used in AC-DC adapters for laptops, mobile phones, and other electronic devices.
• Chargers: Employed in battery chargers for various portable devices.
• Auxiliary Power Supplies: Utilized in auxiliary power supplies for appliances, industrial equipment, and other electronic systems.
• Standby Power Supplies: Found in standby power supplies for minimizing energy consumption in idle mode.
• Open Frame Power Supplies: Used in open-frame power supplies for various electronic applications.

Features:

• Integrated Power MOSFET: Includes an integrated power MOSFET for efficient switching.
• Current Mode PWM Controller: Features a current mode PWM controller for precise output regulation.
• Low Startup Current: Designed for low startup current to minimize power consumption during startup.
• Overvoltage Protection (OVP): Protects the power supply and the load from overvoltage conditions.
• Overload Protection (OLP): Protects the power supply from overload conditions.
• Thermal Shutdown (TSD): Protects the IC from overheating.
• Under Voltage Lockout (UVLO): Prevents operation at low input voltages.

Benefits:

• Cost-Effective: Provides a cost-effective solution for switch-mode power supplies.
• High Efficiency: Achieves high efficiency due to the integrated power MOSFET and PWM controller.
• Compact Size: Reduces the size and cost of power supply systems.
• Protection Features: Overvoltage protection, overload protection, and thermal shutdown enhance reliability.
• Simplified Design: Minimizes the number of external components required.

Additional Details:
