Same model may have multiple batches, images only for reference.
MMBT2907A Real Image MMBT2907A real image3395 MMBT2907A real image3396 MMBT2907A Real Image1 MMBT2907A Real Image2
MMBT2907A Real Image MMBT2907A real image3395 MMBT2907A real image3396 MMBT2907A Real Image1 MMBT2907A Real Image2
Same model may have multiple batches, images only for reference.

MMBT2907A

Part No MMBT2907A
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS PNP 60V 0.6A SOT23
Datasheet
MMBT2907A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Transistor Polarity PNP
Maximum Current Collector 600mA
VCEO Maximum Collector-Emitter Breakdown Voltage 60V
Max Vce (sat) 1.6V @ 50mA, 500mA
Collector Cut-off Current(Max) 10nA (ICBO)
Typical Gain (hFE) (Min) 100 @ 150mA, 10V
Maximum Power Dissipation 300mW
Frequency - Transition 200MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3 (TO-236)
Win Source Part Number 059148-MMBT2907A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MMBT2907A CAD Model

Description

The ON Semiconductor 059148-MMBT2907A is a PNP transistor with a maximum current collector of 600mA and a voltage breakdown of 60V.

  • Maximum current collector: 600mA
  • Voltage breakdown: 60V
  • Maximum power dissipation: 300mW
  • Frequency transition: 200MHz
  • Transistor polarity: PNP
  • Package: SOT-23-3 (TO-236)
  • Suitable for: use in discrete semiconductor products
  • Mounting: SMD (SMT)
  • Supply and demand status: sufficient
