Same model may have multiple batches, images only for reference.

NDC7002N

Name: NDC7002N
Brand: Fairchild/ON Semiconductor
SKU: 251676
Availability: InStock
Rating: 4.85 (1139 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NDC7002N
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET 2N-CH 50V 0.51A SSOT6
Datasheet	NDC7002N Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
FET Type	2 N-Channel (Dual)
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	50V
Continuous Drain Current at 25°C	510mA
Maximum Rds On at Id,Vgs	2 Ohm @ 510mA, 10V
Gate-Source Threshold Voltage	2.5V @ 250μA
Max Gate Charge	1nC @ 10V
Max Input Capacitance	20pF @ 25V
Maximum Power Dissipation	700mW
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SuperSOT-6
Win Source Part Number	025151-NDC7002N
Family Name	NDC7002N
Introduction Date	March 03, 1998
ECCN	EAR99
Country of Origin	Israel, Philippines
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Power Management
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian NDC7002N CAD Model

Alternative Products

Description

The NDC7002N is a dual N-channel FET manufactured by Fairchild/ON Semiconductor.
