NDS7002A

Name: NDS7002A
Brand: Fairchild/ON Semiconductor
SKU: 251782
Availability: InStock
Rating: 4.85 (298 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NDS7002A
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 60V 280MA SOT-23
Datasheet	NDS7002A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	280mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	5V, 10V
Gate-Source Threshold Voltage	2.5V @ 250μA
Max Input Capacitance	50pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	300mW (Ta)
Maximum Rds On at Id,Vgs	2 Ohm @ 500mA, 10V
Temperature Range - Operating	-65°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23 (TO-236AB)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	025169-NDS7002A
Family Name	NDS7002A
Introduction Date	January 04, 1999
ECCN	EAR99
Country of Origin	Philippines, Republic of Korea
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Motor Drive & Control, Industrial
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian NDS7002A CAD Model

Alternative Products

Description

Fairchild/ON Semiconductor NDS7002A is a high-popularity MOSFET component that belongs to the Discrete Semiconductor Products category.

Features: high performance and durability
Maximum Power Dissipation: 300mW
Supply and Demand Status: balanced
Recommendation: purchase this component from a reliable source to avoid any counterfeit products
Commonly used in: power management, motor drive and control, and industrial applications
