NDT456P Fairchild/ON Semiconductor NDT456P Real Image
Same model may have multiple batches, images only for reference.
NDT456P Fairchild/ON Semiconductor NDT456P Real Image
NDT456P Fairchild/ON Semiconductor NDT456P Real Image
Same model may have multiple batches, images only for reference.

NDT456P

Part No NDT456P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 7.5A SOT-223-4 / Trans MOSFET P-CH 30V 7.5A 4-Pin(3+Tab) SOT-223 T/R
Datasheet
NDT456P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 7.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 67nC @ 10V
Max Input Capacitance 1440pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3W (Ta)
Maximum Rds On at Id,Vgs 30 mOhm @ 7.5A, 10V
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 025183-NDT456P
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, Motor Drive & Control
Quantity per package 4k pcs
Family Name NDT456P
Introduction Date March 15, 1999
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian NDT456P CAD Model

Description

The Fairchild/ON Semiconductor component with the Win Source Part Number 025183-NDT456P is a P-channel MOSFET with a maximum power dissipation of 3W (Ta).

  • Family: NDT456P
  • Category: Discrete semiconductor product
  • Supply and Demand Status: Limited
  • Applications: Commonly used in power management, motor drive, and control applications
  • Maximum Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 7.5A (Ta)
  • Gate-Source Threshold Voltage: 3V @ 250μA
  • Maximum Gate Charge: 67nC @ 10V
  • Maximum Input Capacitance: 1440pF @ 15V
  • Maximum Rds On @ Id, Vgs: 30 mOhm @ 7.5A, 10V
  • Halogen-Free: Compliant
  • ECCN Regulations: EAR99
  • Estimated EOL date: 2027
  • Alternative parts: Si8487DB-T1-E1 and NDT456P-Q
