MC705P6ACDWE Real Image MC705P6ACDWE Real Image1 MC705P6ACDWE Real Image2
Same model may have multiple batches, images only for reference.
MC705P6ACDWE Real Image MC705P6ACDWE Real Image1 MC705P6ACDWE Real Image2
MC705P6ACDWE Real Image MC705P6ACDWE Real Image1 MC705P6ACDWE Real Image2
Same model may have multiple batches, images only for reference.

MC705P6ACDWE

Part No MC705P6ACDWE
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description MCU 8-bit HC05 CISC 4672B EPROM 3.3V/5V 28-Pin SOIC W Tube / IC MCU 8BIT 4.5KB OTP 28SOIC
Datasheet
MC705P6ACDWE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tube/Rail
Status Not For New Designs
Core Processor HC05
Part Core Size 8-Bit
Speed(Frequency) 2.1MHz
Number of I/O 21
Program Memory Size 4.5KB (4.5K x 8)
Program Memory Type OTP
Data RAM Size 176 x 8
Supply Voltage - Operating 3 V to 5.5 V
Data Converters A/D 4x8b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 28-SOIC
Win Source Part Number 086584-MC705P6ACDWE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MC705P6A
Introduction Date March 30, 2005
ECCN EAR99
Country of Origin China, United States of America
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian MC705P6ACDWE CAD Model

Description

The NXP MC705P6ACDWE is an 8-bit HC05 core processor integrated circuit designed for use in various applications.

  • Core Processor: HC05
  • Bus Width: 8-bit
  • Package: 28-SOIC
  • Temperature Range: -40°C to 85°C (TA)
  • Supply Voltage: 3 V to 5.5 V
  • I/O Channels: 21
  • Category: Integrated Circuit
  • Popularity: High
  • Lifecycle Status: Not for new designs
