Same model may have multiple batches, images only for reference.
MRF5S9080NBR1 Real Image
Same model may have multiple batches, images only for reference.

MRF5S9080NBR1

Part No MRF5S9080NBR1
Manufacturer Freescale Semiconductor - NXP
Catalog Transistors - FETs, MOSFETs - RF
Description Trans RF MOSFET N-CH 65V 5-Pin TO-272 W T/R / FET RF 65V 960MHZ TO-272-4
Datasheet
MRF5S9080NBR1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer NXP
Packaging Reel - TR
Status Not For New Designs
Transistor Polarity LDMOS
Frequency 960MHz
Gain 18.5dB
Voltage - Test 26V
Current - Test 600mA
Power - Output 80W
Voltage Rating 65V
Case / Package TO-272 WB-4
Win Source Part Number 059517-MRF5S9080NBR1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name MRF5S9080NB
Introduction Date October 01, 2005
ECCN EAR99
Halogen Free Not Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MRF5S9080NBR1 CAD Model

Description

The NXP 059517-MRF5S9080NBR1 is a discrete semiconductor product with a TO-272 WB-4 case/package.

  • Voltage Rating: 65V
  • Frequency: 960MHz
  • Power Output: 80W
  • Current Test: 600mA
  • Transistor Polarity: LDMOS
  • Voltage Test: 26V
  • Gain: 18.5dB
  • Status: Not for new designs and is now obsolete (EOL)
  • Popularity: High popularity
  • Supply and Demand Status: Limited
