1650WA Hammond Manufacturing – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

1650WA

Part No 1650WA
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description XFMR 1.9KCT / 4, 8, 16 CHAS MNT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Impedance - Primary (Ohms) 1.9kCT
Impedance - Secondary (Ohms) 4, 8, 16
DC Resistance (DCR) - Primary 15.65Ohm, 17.19Ohm
DC Resistance (DCR) - Secondary 152mOhm, 203mOhm, 217mOhm
Transformer Type Push-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range 30Hz ~ 30kHz
Frequency Response ±1dB
Voltage - Isolation 3535VDC @ 1 Second
Power Level 280W
Mounting Type Chassis Mount
Size / Dimension 7.500" L x 4.380" W (190.50mm x 111.25mm)
Height - Seated (Max) 5.250" (133.35mm)
Termination Style Wire Leads
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1510981-1650WA
Ultra Librarian 3D Model Ultra Librarian 1650WA CAD Model
