The HFD41-012-H-S is a polarized latching relay manufactured by HongFa. This relay is designed for applications requiring low power consumption and stable switching. Its latching function allows it to maintain its contact position even when power is removed, ideal for applications such as telecommunications, remote control systems, and battery-powered devices.

Applications

• Telecommunications equipment
• Remote control systems
• Battery-powered equipment
• Automatic test equipment
• Security systems

Features

• Polarized latching type
• Low power consumption
• Contact form: 2 Form C (DPDT)
• Contact rating: 0.5A at 125VAC / 1A at 30VDC
• Coil voltage: 12VDC
• High sensitivity
• Sealed Construction
• RoHS compliant

Benefits

• Low Power Consumption: Minimizes energy usage, suitable for battery-operated devices.
• Latching Function: Retains contact position without continuous power, useful for memory retention.
• Compact Size: Suitable for high-density PCB layouts.
• Reliable Switching: Consistent performance over a long operational life.
• Sealed Construction: Protection against dust and other environmental contaminants

Additional Details

The HFD41-012-H-S operates on a 12VDC coil voltage and has a contact rating of 0.5A at 125VAC or 1A at 30VDC. The 2 Form C (DPDT) contact configuration provides switching of two separate circuits. The sealed construction enhances reliability in harsh environments. Insulation resistance is typically 100MΩ minimum at 500VDC. Dielectric strength is 750VAC between coil and contacts and 500VAC between open contacts. The operating temperature range is typically -40°C to +85°C. The latching feature requires correct polarity for proper operation. The relay is mounted through-hole on PCBs.
