BSC011N03LSI

Part No BSC011N03LSI
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 30V 37A 8-Pin TDSON EP T/R / MOSFET N-CH 30V 37A TDSON-8
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 37A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2V @ 250μA
Max Gate Charge 68nC @ 10V
Max Input Capacitance 4300pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta), 96W (Tc)
Maximum Rds On at Id,Vgs 1.1 mOhm @ 30A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TDSON-8
Dimension 8-PowerTDFN
Win Source Part Number 012120-BSC011N03LSI
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name BSC011N03LSI
Introduction Date June 16, 2011
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian BSC011N03LSI CAD Model

Description

BSC011N03LSI from Infineon Technologies is listed in the Transistors - FETs, MOSFETs - RF category and is typically considered for designs that need efficient high-speed switching, RF-related power handling, or compact transistor solutions in demanding electronic systems. Engineers may evaluate parts in this class for telecom hardware, industrial power stages, wireless infrastructure, and other circuits where low-loss operation and reliable performance are important. Infineon is widely recognized for power semiconductor quality, which can make this part relevant for both new design evaluation and maintenance sourcing. The current lifecycle status for BSC011N03LSI is information not available, so procurement teams should confirm whether the device is active, limited, or approaching end-of-life before committing to production. RoHS compliance information is also not available in the provided data. Engineers and compliance teams should verify the latest datasheet, material declaration, and manufacturer documentation before final qualification or volume purchasing.
