The BSC0910NDI is a Smart Switch High-Side Power Switch from Infineon Technologies. This is a single-channel high-side power switch designed for automotive and industrial applications. It provides protection features and diagnostic capabilities for driving various loads.

Applications

• Automotive lighting: Driving and protecting headlights, taillights, and other exterior lighting systems.
• Automotive body control: Controlling door locks, window lifters, and other body control functions.
• Industrial automation: Switching and protecting inductive and resistive loads in industrial equipment.
• Power distribution: High-side switching in power distribution systems.

Features

• High-side switch: Provides load switching on the high side of the power supply.
• Overload protection: Protects the switch and the load from overcurrent conditions.
• Short-circuit protection: Detects and protects against short circuits to ground.
• Overtemperature protection: Shuts down the switch in case of excessive temperature.
• Diagnostic feedback: Provides information about the switch status and fault conditions.
• Logic Level Input: 3.3V and 5V compatible input.

Benefits

• Improved system reliability: Protection features prevent damage to the switch and the load.
• Simplified design: Integrated protection and diagnostic features reduce the need for external components.
• Reduced system cost: Integrated features lower overall system cost.
• Enhanced safety: Protection features ensure safe operation in automotive and industrial environments.

Technical Specifications

• Operating Voltage: Refer to Datasheet (Automotive applications typically 12V/24V)
• On-State Resistance (Rds(on)): Refer to Datasheet
• Maximum Current: Refer to Datasheet
• Protection Features: Overload, Short-circuit, Overtemperature
• Package: PG-DSO-14
