BSZ520N15NS3 G Real Image BSZ520N15NS3 G Real Image1 BSZ520N15NS3 G Real Image2 BSZ520N15NS3 G Real Image3
Same model may have multiple batches, images only for reference.
BSZ520N15NS3 G Real Image BSZ520N15NS3 G Real Image1 BSZ520N15NS3 G Real Image2 BSZ520N15NS3 G Real Image3
BSZ520N15NS3 G Real Image BSZ520N15NS3 G Real Image1 BSZ520N15NS3 G Real Image2 BSZ520N15NS3 G Real Image3
Same model may have multiple batches, images only for reference.

BSZ520N15NS3 G

Part No BSZ520N15NS3 G
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 150V 21A 8-TSDSON
Datasheet
BSZ520N15NS3 G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Series OptiMOS
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 150V
Current - Continuous Drain (Id) @ 25°C 21A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 8V, 10V
Vgs(th) (Maximum) @ Id 4V @ 35μA
Gate Charge (Qg) (Maximum) @ Vgs 12nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 890pF @ 75V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 57W (Tc)
Rds On (Maximum) @ Id, Vgs 52 mOhm @ 18A, 10V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Manufacturer Package PG-TSDSON-8
Package 8-PowerTDFN
Win Source Part Number 795994-BSZ520N15NS3 G
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BSZ520N15NS3 G CAD Model

Description

The Infineon Technologies BSZ520N15NS3 G is a MOSFET from the OptiMOS series.

  • Channel Type: N
  • Drain Source Voltage: 150V
  • Current - Continuous Drain (Id): 21A (Tc)
  • Power Dissipation: 57W (Tc)
  • Rds On: 52 mOhm @ 18A, 10V
  • Gate Charge (Qg) (maximum) @ Vgs: 12nC @ 10V
  • Operating Temperature Range: -55°C to 150°C
  • Input Capacitance (Ciss) (maximum) @ Vds: 890pF @ 75V
