Same model may have multiple batches, images only for reference.
BTS7904S Real Image
Same model may have multiple batches, images only for reference.

BTS7904S

Part No BTS7904S
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N/P-CH 55V/30V 40A 5-Pin(5+Tab) TO-220
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package TO-220-5
Continuous Drain Current (ID) 40 A
Drain to Source Breakdown Voltage 30 V
Drain to Source Resistance 7.2 mΩ
Drain to Source Voltage (Vdss) 30 V
Element Configuration Dual
Input Capacitance 6.1 nF
Maximum Operating Temperature 150 °C
Max Power Dissipation 96 W
Min Operating Temperature -55 °C
Mount Surface Mount
Power Dissipation 96 W
Rds On Max 12 mΩ
RoHS Compliant
Turn-Off Delay Time 104 ns
Win Source Part Number 1004048-BTS7904S
Categories Transistors - FETs, MOSFETs - RF
Manufacturer Infineon Technologies
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian BTS7904S CAD Model

Description

The Infineon Technologies 1004048-BTS7904S is a surface mount dual configuration transistor.

  • Drain to Source Voltage: 30 V
  • Continuous Drain Current: 40 A
  • Rds On Max: 12 mΩ
  • Input Capacitance: 6.1 nF
  • Power Dissipation: 96 W
  • Compliance: Compliant transistor
