Same model may have multiple batches, images only for reference.
IKW60N60H3FKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IKW60N60H3FKSA1

Part No IKW60N60H3FKSA1
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT TRENCH/FS 600V 80A TO247-3 / IGBT Trench Field Stop 600 V 80 A 416 W Through Hole PG-TO247-3
Datasheet
IKW60N60H3FKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - IGBTs - Single
Mfr Infineon Technologies
Series TrenchStop™
Package Tube
IGBT Type Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) 600 V
Current - Collector (Ic) (Max) 80 A
Current - Collector Pulsed (Icm) 180 A
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 60A
Power - Max 416 W
Switching Energy 2.1mJ (on), 1.13mJ (off)
Input Type Standard
Gate Charge 375 nC
Td (on/off) @ 25°C 27ns/252ns
Test Condition 400V, 60A, 6Ohm, 15V
Reverse Recovery Time (trr) 143 ns
Temperature Range - Operating -40°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package PG-TO247-3
Base Product Number IKW60N60
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names IFEINFIKW60N60H3FKSA1,SP000919762,2156-IKW60N60H3FKSA1
Standard Package 240
Win Source Part Number 1064875-IKW60N60H3FKSA1
Ultra Librarian 3D Model Ultra Librarian IKW60N60H3FKSA1 CAD Model

Description

The Infineon Technologies TrenchStop™ IGBT is a high-quality electronic component that is designed to handle a maximum power of 416W and a voltage collector emitter breakdown of up to 600V.

  • Current Collector: up to 80A
  • Current Collector Pulsed: up to 180A
  • Switching Energy: 2.1mJ (on), 1.13mJ (off)
  • Gate Charge: 375nC
  • Mount Type: through-hole mount
  • Package: TO-247-3
  • Temperature Range: -40°C to 175°C (TJ)
