Same model may have multiple batches, images only for reference.

IPD50R950CEAUMA1

Name: IPD50R950CEAUMA1
Brand: Infineon Technologies
SKU: 461028
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	IPD50R950CEAUMA1
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	CONSUMER
Datasheet	IPD50R950CEAUMA1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Infineon Technologies
Series	CoolMOS™ CE
Package	Tape & Reel
Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	500 V
Current - Continuous Drain (Id) @ 25°C	4.3A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	13V
Rds On (Max) @ Id, Vgs	950mOhm @ 1.2A, 13V
Vgs(th) (Max) @ Id	3.5V @ 100µA
Gate Charge (Qg) (Max) @ Vgs	10.5 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	231 pF @ 100 V
Power Dissipation (Max)	53W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-TO252-3-344
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Base Product Number	IPD50R950
Standard Package	2,500 pcs
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	461028-IPD50R950CEAUMA1
Ultra Librarian 3D Model	Ultra Librarian IPD50R950CEAUMA1 CAD Model

Alternative Products

Description

The IPD50R950CEAUMA1 is a single N-channel MOSFET transistor from Infineon Technologies.

Series: CoolMOS™ CE
Vdss: 500V
Id (25°C): 4.3A
Rds On (Max): 950mOhm @ 1.2A and 13V
Package: TO-252-3, DPak
Qg (10V): 10.5nC
Operating Temperature: -55°C to 150°C
Status: Active
REACH: Unaffected
Base Product Number: IPD50R950
