IRF4905PBF Infineon Technologies IRF4905PBF real image IRF4905PBF label picture
Same model may have multiple batches, images only for reference.
IRF4905PBF Infineon Technologies IRF4905PBF real image IRF4905PBF label picture
IRF4905PBF Infineon Technologies IRF4905PBF real image IRF4905PBF label picture
Same model may have multiple batches, images only for reference.

IRF4905PBF

Part No IRF4905PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 55V 74A TO-220AB
Datasheet
IRF4905PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 55V
Continuous Drain Current at 25°C 74A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 180nC @ 10V
Max Input Capacitance 3400pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 200W (Tc)
Maximum Rds On at Id,Vgs 20 mOhm @ 38A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 091644-IRF4905PBF
Family Name IRF4905
Introduction Date November 06, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRF4905PBF CAD Model

Description

The Infineon Technologies 091644-IRF4905PBF is a P-Channel MOSFET transistor with a drain-source breakdown voltage of 55V and continuous drain current at 25°C of 74A (Tc).

  • Drain-Source Breakdown Voltage: 55V
  • Continuous Drain Current @ 25°C: 74A (Tc)
  • Maximum Power Dissipation: 200W (Tc)
  • Gate-Source Threshold Voltage: 4V @ 250μA
