Same model may have multiple batches, images only for reference.

IRF7413TRPBF

Name: IRF7413TRPBF
Brand: Infineon Technologies
SKU: 159929
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF7413TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 13A 8-SOIC
Datasheet	IRF7413TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	13A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	79nC @ 10V
Max Input Capacitance	1800pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	11 mOhm @ 7.3A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	017529-IRF7413TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	IRF7413
Introduction Date	August 25, 1997
ECCN	EAR99
Country of Origin	China, Thailand
Halogen Free	Compliant
Estimated EOL Date	2019
Ultra Librarian 3D Model	Ultra Librarian IRF7413TRPBF CAD Model

Description

The Infineon Technologies IRF7413TRPBF is a N-channel MOSFET with a drain-source breakdown voltage of 30V and a continuous drain current of 13A @ 25°C.

Maximum Rds On @ Id,Vgs: 11 mOhm @ 7.3A, 10V
Maximum Power Dissipation: 2.5W (Ta)
Operating Temperature Range: -55°C to 150°C (TJ)
Package: 8-SO
Mounting: SMD (SMT) technology
Supply and Demand Status: sufficient
