IRF7456TRPBF Infineon Technologies IRF7456TRPBF real image287
Same model may have multiple batches, images only for reference.
IRF7456TRPBF Infineon Technologies IRF7456TRPBF real image287
IRF7456TRPBF Infineon Technologies IRF7456TRPBF real image287
Same model may have multiple batches, images only for reference.

IRF7456TRPBF

Part No IRF7456TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 20V 16A 8-Pin SOIC T/R / MOSFET N-CH 20V 16A 8-SOIC
Datasheet
IRF7456TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 16A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.8V, 10V
Gate-Source Threshold Voltage 2V @ 250μA
Max Gate Charge 62nC @ 5V
Max Input Capacitance 3640pF @ 15V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 2.5W (Ta)
Maximum Rds On at Id,Vgs 6.5 mOhm @ 16A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 017535-IRF7456TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name IRF7456
Introduction Date October 12, 2004
ECCN EAR99
Country of Origin Austria, China, Malaysia, Mexico, Philippines, Taiwan, Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRF7456TRPBF CAD Model

Description

The IRF7456TRPBF is a MOSFET device manufactured by Infineon Technologies.

  • Popularity: High
  • Applications: Various applications where there is a need for a MOSFET
  • Mounting: Surface mount device
  • Maximum Power Dissipation: 2.5W
