Same model may have multiple batches, images only for reference.

IRF9310TRPBF

Name: IRF9310TRPBF
Brand: Infineon Technologies
SKU: 160164
Availability: InStock
Rating: 4.91 (380 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF9310TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 20A 8-SOIC
Datasheet	IRF9310TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.4V @ 100μA
Max Gate Charge	165nC @ 10V
Max Input Capacitance	5250pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	4.6 mOhm @ 20A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	017555-IRF9310TRPBF
Family Name	IRF9310
Introduction Date	March 19, 2010
ECCN	EAR99
Country of Origin	Philippines, Thailand
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Computers & Computer Peripherals
Ultra Librarian 3D Model	Ultra Librarian IRF9310TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRF9310TRPBF is a P-Channel MOSFET that is designed for use in power management applications.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 20A (Tc)
Gate-Source Threshold Voltage: 2.4V @ 100μA
Maximum Gate Charge: 165nC @ 10V
Package: 8-SO
Temperature Range: -55°C to 150°C (TJ)
