IRFB4310ZPBF Real Image IRFB4310ZPBF label picture IRFB4310ZPBF real image326 IRFB4310ZPBF Real Image
Same model may have multiple batches, images only for reference.
IRFB4310ZPBF Real Image IRFB4310ZPBF label picture IRFB4310ZPBF real image326 IRFB4310ZPBF Real Image
IRFB4310ZPBF Real Image IRFB4310ZPBF label picture IRFB4310ZPBF real image326 IRFB4310ZPBF Real Image
Same model may have multiple batches, images only for reference.

IRFB4310ZPBF

Part No IRFB4310ZPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 120A TO-220AB
Datasheet
IRFB4310ZPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 120A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 150μA
Max Gate Charge 170nC @ 10V
Max Input Capacitance 6860pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 250W (Tc)
Maximum Rds On at Id,Vgs 6 mOhm @ 75A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 090724-IRFB4310ZPBF
Family Name IRFB4310Z
Introduction Date March 05, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFB4310ZPBF CAD Model

Description

The Infineon Technologies IRFB4310ZPBF is an N-channel MOSFET designed for use in a variety of applications, including power supplies, motor control, and lighting.

  • Maximum Power Dissipation: 250W (Tc)
  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 120A @ 25°C
  • Gate-Source Threshold Voltage: 4V @ 150μA
  • Maximum Gate Charge: 170nC @ 10V
  • Package: TO-220AB
  • Halogen-Free Compliant: Yes
  • Supply and Demand Status: Sufficient
  • Estimated EOL Date: 2024
