IRFR1010Z Real Image IRFR1010Z real image11753
Same model may have multiple batches, images only for reference.
IRFR1010Z Real Image IRFR1010Z real image11753
IRFR1010Z Real Image IRFR1010Z real image11753
Same model may have multiple batches, images only for reference.

IRFR1010Z

Part No IRFR1010Z
Manufacturer Infineon Technologies
Catalog FETs - Single
Description AUTOMOTIVE MOSFET | MOSFET N-CH 55V 42A DPAK
Datasheet
IRFR1010Z Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 55V
Id - Continuous Drain Current 42A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 7.5mOhm at 42A, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 100μA
Gate Charge (Qg) (Maximum) at Vgs 95nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 2840pF at 25V
Power Dissipation (Maximum) 140W
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Supplier Device Package D-Pak
Manufacturer Package TO-252-3, DPak (2 Leads + Tab), SC-63
Manufacturer Pack Quantity 75
MSL Level 1 (Unlimited)
Win Source Part Number 1187852-IRFR1010Z
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian IRFR1010Z CAD Model

Description

The Infineon Technologies IRFR1010Z is a MOSFET that belongs to the Discrete Semiconductor Products category.

  • Supply and Demand Status: limited
  • Suitable for: various applications, including power management, DC-DC conversion, and load switching
  • Drain-Source Voltage: 55 V
  • Continuous Drain Current: 42 A
  • Power Dissipation: 140 W
