IRFR3607TRPBF Infineon Technologies IRFR3607TRPBF Real Image IRFR3607TRPBF real image358
Same model may have multiple batches, images only for reference.
IRFR3607TRPBF Infineon Technologies IRFR3607TRPBF Real Image IRFR3607TRPBF real image358
IRFR3607TRPBF Infineon Technologies IRFR3607TRPBF Real Image IRFR3607TRPBF real image358
Same model may have multiple batches, images only for reference.

IRFR3607TRPBF

Part No IRFR3607TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 75V 56A DPAK
Datasheet
IRFR3607TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 75V
Continuous Drain Current at 25°C 56A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 100μA
Max Gate Charge 84nC @ 10V
Max Input Capacitance 3070pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 140W (Tc)
Maximum Rds On at Id,Vgs 9 mOhm @ 46A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 017676-IRFR3607TRPBF
Family Name IRFR3607
Introduction Date March 04, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFR3607TRPBF CAD Model

Description

The Infineon Technologies IRFR3607TRPBF is an N-channel polarity MOSFET designed for use in discrete semiconductor products.

  • Mounting technology: surface-mount technology
  • Package: D-Pak case
  • Operating temperature range: -55°C to 175°C
  • Halogen-free: compliant
  • Estimated EOL date: 2024
  • Manufactured in: China
