IRFR4620PBF Real Image IRFR4620PBF real image366 IRFR4620PBF Real Image
Same model may have multiple batches, images only for reference.
IRFR4620PBF Real Image IRFR4620PBF real image366 IRFR4620PBF Real Image
IRFR4620PBF Real Image IRFR4620PBF real image366 IRFR4620PBF Real Image
Same model may have multiple batches, images only for reference.

IRFR4620PBF

Part No IRFR4620PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 24A D-PAK
Datasheet
IRFR4620PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 24A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 100μA
Max Gate Charge 38nC @ 10V
Max Input Capacitance 1710pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 144W (Tc)
Maximum Rds On at Id,Vgs 78 mOhm @ 15A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 205391-IRFR4620PBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRFR4620PBF CAD Model

Description

The Infineon Technologies IRFR4620PBF is a MOSFET semiconductor device that features N-Channel transistor polarity.

  • Category: Discrete Semiconductor Products
  • Package: D-Pak
  • Power Dissipation: 144W (Tc)
  • Continuous Drain Current: 24A (Tc)
  • Drain-Source Breakdown Voltage: 200V
  • Maximum Gate-Source Voltage: ±20V
  • Input Capacitance: 1710pF @ 50V
  • Drive Voltage: 10V
  • Gate-Source Threshold Voltage: 5V @ 100μA
  • Maximum Rds On at Id,Vgs: 78 mOhm @ 15A, 10V
  • Operating Temperature Range: -55°C to 175°C (TJ)
