IRFU2307ZPBF Infineon Technologies IRFU2307ZPBF real image
Same model may have multiple batches, images only for reference.
IRFU2307ZPBF Infineon Technologies IRFU2307ZPBF real image
IRFU2307ZPBF Infineon Technologies IRFU2307ZPBF real image
Same model may have multiple batches, images only for reference.

IRFU2307ZPBF

Part No IRFU2307ZPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 75V 42A I-PAK
Datasheet
IRFU2307ZPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 75V
Continuous Drain Current at 25°C 42A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 100μA
Max Gate Charge 75nC @ 10V
Max Input Capacitance 2190pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 110W (Tc)
Maximum Rds On at Id,Vgs 16 mOhm @ 32A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package IPAK (TO-251)
Dimension TO-251-3 Short Leads, IPak, TO-251AA
Win Source Part Number 205406-IRFU2307ZPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFU2307ZPBF CAD Model

Description

The Infineon Technologies 205406-IRFU2307ZPBF is a MOSFET electronic component that is used in various electronic devices.

  • Drain-Source Breakdown Voltage: 75V
  • Continuous Drain Current: 42A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 4V @ 100μA
