Same model may have multiple batches, images only for reference.

IRLR8743TRPBF

Name: IRLR8743TRPBF
Brand: Infineon Technologies
SKU: 161649
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRLR8743TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 30V 160A 3-Pin(2+Tab) DPAK T/R / MOSFET N-CH 30V 160A DPAK
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	160A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.35V @ 100μA
Max Gate Charge	59nC @ 4.5V
Max Input Capacitance	4880pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	135W (Tc)
Maximum Rds On at Id,Vgs	3.1 mOhm @ 25A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D-Pak
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	017812-IRLR8743TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRLR8743
Introduction Date	August 15, 2007
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IRLR8743TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRLR8743TRPBF MOSFET is a high popularity N-Channel electronic component with a drain-source breakdown voltage of 30V.

Continuous Drain Current: 160A (Tc) @ 25°C
Maximum Gate Charge: 59nC @ 4.5V
Power Dissipation: 135W (Tc)
Package: Reel - TR
Mounting: SMD (SMT) technology
Supply and Demand Status: Balanced
Halogen-Free: Yes
