IRSM005-301MHTR

Part No IRSM005-301MHTR
Manufacturer Infineon Technologies
Catalog PMIC - Full, Half - Bridge Drivers
Description IC GATE DRIVER 100V QFN / Half Bridge Driver AC Motors, DC Motors, DC-DC Converters, General Purpose Power MOSFET 27-PQFN (7x8)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Full, Half-Bridge Drivers
Mfr Infineon Technologies
Series µIPM™
Package Tape & Reel (TR)
Output Configuration Half Bridge
Applications AC Motors, DC Motors, DC-DC Converters, General Purpose
Interface Logic
Load Type Inductive, Capacitive
Technology Power MOSFET
Rds On (Typ) 16mOhm
Current - Output / Channel 30A
Voltage - Supply 10V ~ 20V
Voltage - Load 100V (Max)
Temperature Range - Operating 150°C (TJ)
Features Bootstrap Circuit
Fault Protection UVLO
Mounting SMD (SMT)
Package / Case 27-PowerVQFN
Supplier Device Package 27-PQFN (7x8)
Base Product Number IRSM005
Other Names SP001540888,INFINFIRSM005-301MHTR,2156-IRSM005-301MHTR
Standard Package 2,000
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1253561-IRSM005-301MHTR
Ultra Librarian 3D Model Ultra Librarian IRSM005-301MHTR CAD Model

Description

The Infineon Technologies 1253561-IRSM005-301MHTR is a µIPM™ full-bridge driver for use in motor control and power conversion applications.

  • Output Configuration: half-bridge
  • Maximum Load Voltage: 100 V
  • Current Rating: 30 A
  • Typical On-Resistance: 16 mOhm
  • Package: 27-PowerVQFN package
  • Suitable for: surface mount applications
  • Ideal for: use in a wide range of applications, including AC and DC motors, DC-DC converters, and other power conversion applications
