The IRF7404 is a P-Channel HEXFET® Power MOSFET from International Rectifier. This MOSFET is designed for high-efficiency power switching and load management applications. Its low on-resistance and gate charge contribute to efficient power conversion.

Applications:

• Load Switching
• DC-DC converters
• Power Management
• Battery Management
• Motor control

Features:

• P-Channel MOSFET
• Low RDS(on)
• Low Gate Charge
• Surface Mount (SO-8) Package
• Logic-Level Compatible

Benefits:

• Efficient power conversion due to low on-resistance and gate charge
• Simplified driving requirements with logic-level compatibility
• Compact design with SO-8 package
• Suitable for portable and battery-powered applications
• Reduced switching losses

Additional Details:

The IRF7404 has a drain-source voltage (VDS) rating of -40V and a gate-source voltage (VGS) rating of ±20V. The on-resistance (RDS(on)) is typically around 0.035 Ohms at VGS = -10V. The gate threshold voltage is typically between -1V and -3V. The maximum continuous drain current is -9.3A. It comes in a SO-8 package for surface mount assembly. The device's low on-resistance reduces conduction losses. It's ideal for applications requiring efficient load switching. The operating temperature range is -55°C to +175°C. The device is RoHS compliant. The low gate charge contributes to high-speed switching performance.
