Same model may have multiple batches, images only for reference.
PHE840EA5100MA01R17 KEMET – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PHE840EA5100MA01R17

Part No PHE840EA5100MA01R17
Manufacturer Kemet
Catalog Film Capacitors
Description CAP FILM RAD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category CapacitorsFilm Capacitors
Mfr KEMET
Series PHE840E
Packaging Box
Part Status Not For New Designs
Capacitance 10000 pF
Tolerance ±20%
Voltage Rating - AC 300V
Voltage Rating - DC 760V
Dielectric Material Polypropylene (PP), Metallized
Operating Temperature -55°C ~ 105°C
Mounting Type Through Hole
Package / Case Radial
Size / Dimension 0.512" L x 0.157" W (13.00mm x 4.00mm)
Height - Seated (Max) 0.354" (9.00mm)
Termination PC Pins
Lead Spacing 0.394" (10.00mm)
Applications EMI, RFI Suppression
Ratings X2
Ultra Librarian 3D Model Ultra Librarian PHE840EA5100MA01R17 CAD Model
