Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Main Purpose DC/DC, Step Down
Outputs and Type 2, Non-Isolated
Voltage - Output 1.2V, 3.3V
Output Current 1A, 800mA
Voltage - Input 5 V ~ 35 V
Regulator Topology Buck
Frequency - Switching 2MHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part LT3640
Win Source Part Number 781154-DC1359A
Popularity Medium
Supply and Demand Status Limited
Introduction Date July 19, 2010
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC1359A CAD Model

Description

Introducing the DC1359A Demonstration Board from Linear Technology

The DC1359A is a high-performance demonstration board presented by Linear Technology, now part of Analog Devices, that showcases the LTC®2315-14, a 14-bit, 4.5Msps, serial sampling A/D converter (ADC) that combines excellent DC accuracy and AC performance with a wide input bandwidth. This demonstration board is designed to help engineers evaluate the capabilities of the LTC2315-14 in a convenient and effective manner.

With its high-speed SPI-compatible serial interface, the DC1359A can be easily connected to most microcontroller or digital signal processor (DSP) platforms for data acquisition systems. The LTC2315-14 ADC features a flexible input range and a conversion rate that is suitable for a wide array of applications, including medical imaging, communications, and industrial process control.

Key Features of DC1359A:

  • High-Speed ADC: The LTC2315-14 offers a 14-bit resolution at a sampling rate of up to 4.5Msps, ensuring high-speed data capture with precise accuracy.
  • Wide Input Range: Users can benefit from the ADC's wide input range, which provides flexibility in accommodating various signal types.
  • Low Power Consumption: Designed for efficient operation, the LTC2315-14 helps in minimizing power usage, making it ideal for portable and battery-powered applications.
  • Easy Integration: The demonstration board includes an SPI interface for straightforward integration with existing digital systems.
  • No Pipeline Delay: The ADC technology used in the DC1359A features no pipeline delay, which is crucial for real-time and multiplexed systems that require immediate data processing.

The DC1359A demonstration board comes equipped with all necessary components to showcase the LTC2315-14's performance right out of the box. It also provides test points and jumpers for easy evaluation of the ADC's various features and functions. Whether for prototyping or for learning purposes, the DC1359A is a valuable tool for any developer looking to leverage high-speed ADC technology in their designs.

With Linear Technology's commitment to quality and performance, the DC1359A demonstration board stands as a testament to their expertise in analog and mixed-signal engineering. By choosing the DC1359A, developers are assured a robust platform for testing and integrating high-speed ADC technology into their next groundbreaking project.
