Linear Technology's LT3652HVEMSE#TRPBF Power Tracking Battery Charger

The LT3652HVEMSE#TRPBF is a highly sophisticated power tracking battery charger IC designed by Linear Technology, which specializes in managing solar power efficiently to charge a variety of battery types. This innovative component is engineered to precisely control the charging process of batteries, optimizing the energy utilization from solar panels or other high impedance power sources.

This charger is a variant of the LT3652, with the HV indicating a 'high voltage' capability, making it particularly well-suited for applications that require charging from sources that can provide higher voltages. The LT3652HVEMSE#TRPBF operates over a wide input voltage range from 4.95V to 34V, which is reduced to 4.4V after the start-up, ensuring versatility in various power environments.

The device is designed to charge a broad spectrum of battery chemistries, including Lithium-Ion/Polymer, Lead-Acid, and LiFePO4 batteries. It is capable of delivering up to 2A of continuous charge current, adjustable via a single resistor. The LT3652HVEMSE#TRPBF employs a 3.3V float voltage feedback reference, enabling the user to set the float voltage to suit the specific battery chemistry and number of cells via a simple resistor divider.

One of the key features of this charger is its PowerPath control, which manages the power distribution between the load and the battery. This feature ensures that the system remains operational even when the input power is limited or unavailable. The LT3652HVEMSE#TRPBF also includes an internal thermal feedback mechanism that regulates the charge current to maintain a safe temperature during operation.

Other notable features include its MPPT (Maximum Power Point Tracking) capability, which maximizes the energy harvested from solar panels, and its ability to provide a constant-current/constant-voltage charge algorithm with programmable charge termination. The device is also equipped with a range of safety features such as input supply overvoltage protection, battery temperature sensing and monitoring, and NTC thermistor interface for temperature-qualified charging.

The LT3652HVEMSE#TRPBF is packaged in a compact 12-pin MSOP package with an exposed pad for enhanced thermal performance, making it an excellent choice for space-constrained portable applications. It is a robust solution for energy-conscious, environmentally friendly power management in a variety of applications including solar-powered systems, portable instruments, and industrial equipment.
