Linear Technology LTC1746CFW Product Overview

The LTC1746CFW is a high-performance, 16-bit, 50Msps analog-to-digital converter (ADC) designed by Linear Technology to meet the demanding requirements of communication systems, imaging, and high-speed signal processing applications. It is a member of Linear Technology's extensive ADC product line, known for its precision and reliability.

Key Features

• Resolution: 16-bit resolution provides high precision for demanding applications.
• Sampling Rate: Fast sampling rate of up to 50Msps (Mega samples per second) ensures accurate digitization of high-frequency signals.
• Input Range: The device features a wide input range, making it versatile for various signal types.
• Low Power Consumption: Designed with power efficiency in mind, the LTC1746CFW is ideal for battery-powered and portable devices.
• Easy Interface: The ADC includes a parallel LVDS output to facilitate easy and quick data transfer.

Applications

The LTC1746CFW is suitable for a wide array of applications, including:

• Telecommunications
• Medical Imaging
• Radar and Satellite Systems
• Digital Oscilloscopes
• Test and Measurement Equipment

Performance and Quality

Linear Technology's LTC1746CFW is designed to deliver high-fidelity performance and is built to the highest quality standards. The ADC features excellent dynamic performance, including SNR (Signal-to-Noise Ratio) and SFDR (Spurious-Free Dynamic Range), ensuring that signals are captured with high accuracy and minimal distortion.

Package Information

The LTC1746CFW is available in a 48-pin TSSOP package, which is compact and suitable for space-constrained applications. Its footprint is compatible with industry standards, allowing for straightforward integration into existing designs.

Support and Reliability

Linear Technology provides comprehensive technical support for the LTC1746CFW, including datasheets, application notes, and design resources. Customers can rely on the renowned Linear Technology quality and support for their high-performance ADC needs.
